[USB power supply] The wall lamp is powered by a USB power cord (attached); which can be connected to the power library; computer; laptop; so you can use it in more scenes.
[Customize your space with the fun of DIY] Fast modular components are equivalent to a system; which can easily adapt to any scene. Connect the lights together to create the structure that best fits indoors. There is no dark area on the surface; and the seam is seamless. It can form various shapes; show gorgeous and amazing effects; and create a romantic and happy atmosphere
[Follow the music] The light can react to the music; and you can become a DJ with the light. [Color charging] Hexagonal lamps use high-quality LEDs to create bright colors; making them stand out in the dark at night. 7 colors can be adjusted; with any color combination you like. Color rechargeable wall lamp can immerse you in the game.
[2 control methods] Quantum lamp has two control methods: remote control and mobile phone APP control. You can set multiple modes to control the light.
[Decorative wall lamp] Hexagonal rhythm lamp is very suitable for family decoration and mural painting; creating an interesting and lively atmosphere in the bedroom; living room; game room; children; teenagers; girls; babies and game room.
Specifications: Control mode: APP/1R/key Operating temperature: - 20 ℃~60 ℃ Power: 1.5W/piece Power supply voltage: DC5V (Each DC5V2A power supply can load 15 pcs of modules; and additional power supply and supporting power expansion line are required if the module is exceeded) the
Installation Instructions 1. Please make the modeling layout plan in advance or prefabricate the modeling on the desktop and define the entrance position of the drive control line. 2. Remove the release paper on one side of the double-sided adhesive tape; stick the double-sided adhesive tape on the center of the back of the module; and remove the release paper on the other side of the adhesive tape before installation. (This step is omitted for desktop installation)
3. First locate the entrance module of the drive control line; and then insert the connecting piece arrow to the end (NEXT end) into the cascade module and insert the "PRE" end of the connecting piece into the previous module according to the sequence of the modeling plan to complete the installation. 4. Insert the USB end of the drive control cable into the first module; and then insert the other end of the drive control cable into any signal output port corresponding to the pickup; and then p
